Network Architecture in ISO 27799

Network Architecture in ISO 27799

$349.00
How you learn:
Self-paced • Lifetime updates
Who trusts this:
Trusted by professionals in 160+ countries
Your guarantee:
30-day money-back guarantee — no questions asked
When you get access:
Course access is prepared after purchase and delivered via email
Toolkit Included:
Includes a practical, ready-to-use toolkit containing implementation templates, worksheets, checklists, and decision-support materials used to accelerate real-world application and reduce setup time.
Adding to cart… The item has been added

This curriculum spans the equivalent of a multi-workshop technical advisory engagement, addressing network architecture decisions, segmentation enforcement, encryption deployment, and compliance validation across clinical environments in alignment with ISO 27799’s security controls.

Module 1: Aligning Network Design with ISO 27799 Information Security Objectives

  • Decide whether to segment clinical data flows from administrative traffic based on confidentiality requirements in ISO 27799 clause 5.1.1.
  • Implement network zoning that reflects data sensitivity classifications defined in organizational policy and mapped to ISO 27799 A.8.2.1.
  • Balance encryption overhead against real-time performance needs for medical imaging transfers across WAN links.
  • Evaluate whether existing network monitoring tools satisfy the audit logging requirements in ISO 27799 A.12.4.1 for health information access.
  • Configure VLANs to enforce separation between guest Wi-Fi and systems handling protected health information (PHI).
  • Document network architecture decisions in a security rationale register to support ISO 27799 compliance audits.
  • Integrate network availability targets with business continuity plans as required by ISO 27799 A.17.2.1.
  • Assess third-party cloud connectivity models against data residency obligations under health privacy regulations cited in ISO 27799.

Module 2: Secure Network Segmentation for Healthcare Environments

  • Design firewall rule sets that enforce least-privilege access between EMR systems and laboratory devices.
  • Implement micro-segmentation for virtualized diagnostic applications using host-based firewalls and group policies.
  • Decide between physical and logical separation for radiology PACS based on throughput and threat exposure.
  • Configure DMZs for external health information exchanges while preventing lateral movement to internal systems.
  • Enforce segmentation controls at the hypervisor level for multi-tenant clinical SaaS platforms.
  • Map network segments to data flow diagrams required by ISO 27799 A.8.1.1 for risk assessment.
  • Validate segmentation effectiveness through periodic penetration testing and rule set reviews.
  • Coordinate segmentation changes with clinical workflow updates to avoid unintended service disruption.

Module 3: Encryption and Data-in-Transit Protection Strategies

  • Select TLS 1.3 over IPsec for web-based patient portals based on endpoint compatibility and manageability.
  • Deploy mutual TLS authentication between pharmacy systems and prescription drug monitoring programs.
  • Implement certificate lifecycle management for network devices to prevent outages due to expired certificates.
  • Configure hardware security modules (HSMs) to protect encryption keys used in health data replication.
  • Balance end-to-end encryption with the need for deep packet inspection by security monitoring tools.
  • Enforce encrypted connections between mobile health apps and backend APIs using certificate pinning.
  • Document encryption standards in network design specifications to ensure vendor compliance during procurement.
  • Test failover behavior of encrypted tunnels during network congestion or partial outages.

Module 4: Identity-Aware Network Access Control

  • Integrate 802.1X with Active Directory to restrict network access based on clinical role and device type.
  • Configure NAC policies to quarantine medical devices that fail firmware or patch compliance checks.
  • Implement dynamic VLAN assignment for visiting clinicians based on temporary access credentials.
  • Enforce multi-factor authentication for administrative access to core network infrastructure.
  • Map RADIUS attributes to ISO 27799 access control policies for audit trail consistency.
  • Coordinate NAC exceptions for legacy medical equipment with risk acceptance documentation.
  • Monitor and log all authentication attempts to network infrastructure for anomaly detection.
  • Test NAC policy enforcement during failover to backup directory services.

Module 5: Secure Integration of Medical IoT and Legacy Devices

  • Isolate infusion pumps and patient monitors on dedicated VLANs with egress filtering to clinical servers only.
  • Implement protocol translation gateways for legacy HL7 v2 systems that cannot support modern encryption.
  • Deploy network-based behavioral analytics to detect anomalous traffic from embedded medical devices.
  • Establish compensating controls for devices with hardcoded credentials as permitted under risk assessment.
  • Coordinate firmware update windows with clinical schedules to minimize patient care disruption.
  • Use network access control to prevent unauthorized USB-to-Ethernet adapters on diagnostic equipment.
  • Document device communication patterns to support forensic investigations after security incidents.
  • Enforce MAC address filtering on switch ports connected to life-critical monitoring systems.

Module 6: Resilient Network Design for Clinical Continuity

  • Design redundant core switches with non-blocking backplanes to maintain EMR responsiveness during failover.
  • Implement BGP routing with multiple ISPs to ensure connectivity for telehealth services.
  • Validate failover timing of network components against clinical application recovery time objectives (RTOs).
  • Deploy load balancers with health checks to route traffic away from degraded clinical application servers.
  • Size WAN links to support surge capacity during public health emergencies or disaster response.
  • Test network redundancy during scheduled maintenance with clinical stakeholders present.
  • Configure QoS policies to prioritize voice and video traffic for remote patient consultations.
  • Document single points of failure in network diagrams and track mitigation in the risk register.

Module 7: Monitoring, Logging, and Threat Detection

  • Aggregate firewall, switch, and router logs into a SIEM with retention aligned to ISO 27799 A.12.4.1.
  • Configure NetFlow collection to baseline normal traffic patterns for early anomaly detection.
  • Deploy network TAPs or SPAN ports to feed IDS sensors without impacting production performance.
  • Define alert thresholds for unusual data exfiltration volumes from clinical departments.
  • Correlate network events with user authentication logs to detect lateral movement.
  • Implement encrypted log transmission to prevent tampering with audit trails.
  • Validate log synchronization across network devices using NTP with access controls.
  • Conduct quarterly log review simulations to test incident detection and response readiness.

Module 8: Third-Party and Cloud Connectivity Governance

  • Negotiate SLAs with cloud EHR providers that specify network performance and availability metrics.
  • Implement secure hybrid connectivity using IPsec or AWS Direct Connect for cloud-hosted health apps.
  • Enforce data loss prevention (DLP) policies at network egress points for cloud-bound PHI.
  • Validate that colocation providers meet physical security requirements in ISO 27799 A.11.1.1.
  • Configure DNS filtering to block connections from clinical networks to known malicious domains.
  • Review third-party network architecture diagrams during vendor onboarding for compliance gaps.
  • Isolate connections to billing and claims processors using dedicated circuits or VRFs.
  • Conduct annual reviews of shared network responsibilities in cloud service agreements.

Module 9: Change Management and Network Configuration Governance

  • Enforce change freeze periods around peak clinical operations such as admissions or shift changes.
  • Require peer review of firewall rule changes to prevent overly permissive access grants.
  • Automate configuration backups for all network devices on a daily basis.
  • Implement version control for network device configurations using Git or similar tools.
  • Validate rollback procedures for core network changes in a staging environment.
  • Link network change requests to risk assessment outcomes for audit traceability.
  • Restrict CLI access to network devices through jump servers with session recording.
  • Conduct post-implementation reviews for major network upgrades to capture lessons learned.

Module 10: Audit Readiness and Continuous Compliance Validation

  • Map network controls to specific ISO 27799 control objectives for auditor reference.
  • Generate network compliance reports showing firewall rule recertification and patch status.
  • Conduct internal technical audits of switch and router configurations against hardening baselines.
  • Prepare network topology diagrams that reflect current state for regulatory submissions.
  • Validate encryption coverage across all data-in-transit scenarios involving PHI.
  • Review access logs for administrative network accounts during compliance assessment cycles.
  • Perform annual penetration tests focused on network-layer vulnerabilities in clinical zones.
  • Update network risk assessment documentation to reflect changes in threat landscape or infrastructure.
!
