Pipeline Infrastructure in Oil Drilling

Pipeline Infrastructure in Oil Drilling

$249.00
Who trusts this:
Trusted by professionals in 160+ countries
When you get access:
Course access is prepared after purchase and delivered via email
Toolkit Included:
Includes a practical, ready-to-use toolkit containing implementation templates, worksheets, checklists, and decision-support materials used to accelerate real-world application and reduce setup time.
How you learn:
Self-paced • Lifetime updates
Your guarantee:
30-day money-back guarantee — no questions asked
Adding to cart… The item has been added

This curriculum spans the technical and operational rigor of a multi-phase pipeline engineering program, comparable to the integrated planning, construction, and compliance workflows managed during actual oilfield development projects involving cross-functional teams and regulatory audits.

Module 1: Pipeline Material Selection and Corrosion Management

  • Specify carbon steel grade (e.g., API 5L X60 vs X70) based on wellhead pressure, H2S content, and sour service requirements per NACE MR0175.
  • Design corrosion-resistant alloy (CRA) cladding for pipelines in high-CO2 environments, balancing cost against expected service life and inspection intervals.
  • Implement internal corrosion monitoring using corrosion coupons and electrical resistance probes at critical flow junctures.
  • Evaluate the use of solid-dissimilar metal welds versus transition joints when connecting CRA-lined pipe to carbon steel headers.
  • Define coating specifications for external pipeline surfaces based on soil resistivity and cathodic protection feasibility in offshore trenching scenarios.
  • Establish inspection protocols for stress corrosion cracking (SCC) in high-pH environments, particularly in onshore buried sections near compressor stations.

Module 2: Pipeline Route Planning and Geotechnical Assessment

  • Conduct route optimization studies to avoid fault lines, landslide-prone slopes, and permafrost zones in Arctic drilling operations.
  • Integrate bathymetric and sub-bottom profiler data when routing subsea pipelines across continental slopes.
  • Coordinate with seismic survey teams to identify shallow gas pockets that could compromise pipeline trench stability.
  • Obtain right-of-way (ROW) easements while addressing landowner constraints and environmental buffer zones near water crossings.
  • Assess soil lateral resistance values to determine required burial depth for pipeline buckling prevention under thermal expansion.
  • Model pipeline interaction with existing infrastructure, such as electrical cables and communication lines, to avoid excavation conflicts.

Module 3: Pipeline Design and Engineering Standards Compliance

  • Apply ASME B31.4 and B31.8 standards to determine wall thickness based on maximum allowable operating pressure (MAOP) and design factor derating.
  • Perform limit state design for pipelines subject to combined axial, bending, and thermal loads in floating production systems.
  • Size expansion loops and stress analysis at riser connections to accommodate platform movement in deepwater environments.
  • Validate pipeline support spacing to prevent span-induced vortex-induced vibration (VIV) in suspended offshore sections.
  • Calculate hydrostatic test pressures at 1.25 to 1.5 times MAOP, considering elevation differentials across hilly terrain.
  • Document design basis reports that justify load cases, safety factors, and code exemptions for regulatory audits.

Module 4: Pipeline Construction and Welding Oversight

  • Supervise field welding procedures using qualified WPS (Welding Procedure Specifications) and PQRs (Procedure Qualification Records) under ASME IX.
  • Enforce pre-weld joint preparation standards, including bevel angle tolerances and root face control in girth welds.
  • Deploy real-time radiographic testing (RT) or phased array ultrasonic testing (PAUT) for critical welds in high-consequence areas.
  • Manage welding in adverse weather conditions by implementing windbreaks and preheat requirements per ambient temperature thresholds.
  • Track weld traceability using digital logbooks that link welder IDs, joint numbers, and NDT results for audit purposes.
  • Coordinate tie-in spool fabrication at offshore platforms using laser scanning for precise dimensional matching.

Module 5: Pipeline Installation and Commissioning

  • Oversee S-lay or J-lay operations for subsea pipelines, adjusting tensioner settings based on water depth and stinger angle.
  • Manage pipeline pull-in procedures at manifold hubs using ROVs and tension monitoring to prevent overstress.
  • Execute sequential pigging runs: foam pigs, bidirectional cleaning pigs, and geometry pigs prior to hydrotesting.
  • Conduct dewatering and nitrogen inerting of pipelines to prevent hydrate formation during first oil introduction.
  • Monitor pressure ramp rates during hydrostatic testing to avoid water hammer effects in long pipeline segments.
  • Validate valve alignment and block valve operability during pre-commissioning checkouts using SCADA integration.

Module 6: Pipeline Integrity Management and In-Line Inspection

  • Develop ILI (In-Line Inspection) programs using MFL (Magnetic Flux Leakage) and ultrasonic tools to detect metal loss and cracks.
  • Assess dent-gouge interactions in dented areas to determine whether pipeline section requires repair or can remain in service.
  • Classify anomalies per API 1163 and ASME B31.8S, prioritizing repairs based on depth, length, and proximity to stress concentrators.
  • Implement automatic feature recognition (AFR) software to reduce false calls in ILI data interpretation.
  • Design repair strategies using composite wraps, sleeves, or cut-out spools based on operating pressure and accessibility.
  • Update maximum allowable operating pressure (MAOP) following integrity assessments and re-rating calculations.

Module 7: Pipeline Operations and Leak Detection Systems

  • Configure mass balance and statistical volume monitoring systems to detect leaks as small as 1.5% of flow rate.
  • Integrate SCADA-based negative pressure wave detection with third-party software for rapid anomaly response.
  • Calibrate flow meters at custody transfer points using provers or ultrasonic calibration to meet fiscal metering standards.
  • Implement batch tracking for multi-product pipelines to prevent contamination during product changeovers.
  • Manage transient flow conditions during pump start-up and shut-down to avoid column separation and surge pressures.
  • Conduct routine valve stroke testing and emergency shutdown (ESD) drills to ensure system responsiveness.

Module 8: Regulatory Compliance and Emergency Response Planning

  • Prepare OPS Form 7100-1 submissions for PHMSA in accordance with pipeline safety regulations for onshore hazardous liquid lines.
  • Develop High Consequence Area (HCA) assessments using population density, navigable waterways, and environmental sensitivity data.
  • Conduct pipeline risk assessments using quantitative risk analysis (QRA) for permitting in ecologically sensitive zones.
  • Coordinate with local emergency responders to conduct tabletop drills for pipeline rupture scenarios near populated areas.
  • Implement API 1173 requirements for pipeline safety management systems, including management review and continual improvement.
  • Document incident investigations using root cause analysis (RCA) methods such as TapRooT for regulatory reporting and corrective actions.
!
